RS232 to I2C EEPROM Memory Kit is an Electronics board that allows you to connect EEPROM Memory sensor to your Personal Computer (PC) Communication Port (COMM. PORT).

No need for external Power supply! The board is powered directly from your PC COM port.

Kit Includes:

• 24C04    EEPROM           1pc.

• 100MF    Capacitor         1pc.

• 22MF      Capacitor        1pc.

• 0.1MF     Capacitor        2pc.

• 4.7K       Resistor           2pc.

• 1N4148   Diode              2pc.

• 1N4733A Zener Diode      2pc.

• LM2936Z-5 Voltage Reg. 1pc.

• DB9 Male type               1pc.

• PCB                             1pc.

Free Software:

Version 3.00ES (Win95/98/2000/XP) is coming soon.

Schematic:

Description and SKU#

Price


RS232 to I2C 2 Temp Sensors Kit

EID-K-RS2-32-I2CE-ASM    Fully assembled

EID-K-RS2-32-I2CE-KIT     Kit

42.45

27.33

RS232 to I2C  Kit

EID-K-RS2-32-I2CXX-PCB    PCB Only

15.33

Serial Port Complete (Second Edition) by J. Alexson

EID-K-BOOK-SERIAL-001  Regular price

EID-K-BOOK-SERIAL-0KC  w/ kit purchase

NEW! We carry technical books...

LEARN & SAVE!

This is a "must have" book for any student or engineer. Therefore, an additional 10% off for student with student ID!

39.95

27.33

  ^•
